High Efficiency Hybrid Mppt 5kw Solar Inverter Off Grid Solar System Solar Battery System

Model: BAH5000

Input voltage: DC 48V

Output voltage: AC110V/220V

Rated power: 5000W

Super power: 10000VA

Efficiency:  93%

Transfer time: 10 ms (for personal computer); 20 ms(for household appliance)

Waveform:  Pure sine wave

Battery voltage:  48VDC

Floating charging current: 54VDC

Over charge protection: 63VDC

Maximum PV array open circuit voltage: 500VDC

Maximum PV array power: 5000W

MPPT range at working voltage: 120-450VDC

Maximum PV charging current: 80A

Maximum AC charging current: 80A

Maximum charging current: 80A

Product size: 300*100*440mm

Net weight:  10KG

Relative humidity: 5%-95%

Working temperature: -10°C~50°C

Storage temperature: -15°C~60°C
